MIL-P-18140(SHIPS)
3.9.4.4 Tools which are available in the Catalog of Naval Material, General Stores Section, such
as common wrenches and standard pullers, will not be required. Standard complete or limited sets of
pullers or parts of puller sets in accordance with Specification GGG-P-781 shall be identified as to type
and use in notes on the outline or section assembly drawings. Special tools shall be detailed, and
included in the list of material.
3.9.4.5 Each box containing onboard repair parts shall contain a list entitled "List of onboard
repair parts and tools", The list shall be in a format suitable for use on outline drawings and in the
instruction books, It shall not be less than nominal 8-1/2 by 11 inches in size.
3.9.4.5.1 The format of the list shall include a heading and columns of data for the items listed,
The heading shall include titles and applicable entries as follows:
Reproduced from drawing number
Number of ships
Application
Contract number
Manufacturer
Quantities are for
units per ship
The columns shall include:
Piece number
Name of part
Quantity
Drawing number
Standard Navy stock number
Additional columns may be used as applicable
3.9.4.5.2 The list shall be so treated as to be resistant to oil, water and fading.
3.9.5 Stock. - The selection, stock numbering and quantities of repair parts for stock shall be
determined and processed in accordance with Specification MIL-R-15137.
3.9.5. i Unless otherwise specified in the contract or order, the cognizant supply demand control
point for repair parts for stock shall be Ships Parts Control Center, Mechanicsburg, Pennsylvania.
4. QUA LITY ASSURANCE PROVISIONS
4.1 Classification of tests, - Tests shall be classified as follows:
(a) Qualification tests.
(b) Performance acceptance tests,
(c) Hydrostatic tests,
4.2 Qualification tests at a Government laboratory. - Qualification tests shall be conducted at a
Government laboratory designated by the Bureau of Ships. These tests shall consist of the tests specified
in 4.2.7,
4.2, 1 Pumps submitted for qualification tests shall have characteristic ratings of not less than the
following:
R a t e d capacity ----------------------- 200 g. p. m.
Discharge pressure ------------------ 100 p, s. i.
Suction lift - - - - - - - - - - - - - - - - - - - - - - - - - - - 15 inches Hg. at 450 SSU.
25 inches Hg. at 7000 SSU.
