MIL-P-17574D(YD)
4.5 Packaging inspection. The preservation, packing, and marking of the
pump-engine system shall be inspected to the requirements of section 4 of
When specified (see 6.2), a preproduction pack inspection shall be
MIL-P-10603.
performed in accordance with MIL-P-10603.
5.
PACKAGING
The pump-engine system shall be
5.1 Preservation, packing, and marking
packaged, packed, and marked in accordance with MIL-P-10603. The level of
preservation and level of packing shall be as specified (see 6.2).
6.
NOTES
(This section contains information of a general or explanatory nature that
may be helpful, but is not mandatory.)
6.1 Intended use. The pump-engine systems are intended for applications at
temporary and semi-permanent installations for handling fresh or salt water,
gasoline, fuel oil, or diesel oil.
6.1.1 Selection factors.
a.
Fungus resistant varnish conforming to MIL-V-173 should be used to
coat electrical components and circuit elements, including terminal
and circuit connections, when the system is to be installed in humid
Components and elements inherently inert to fungi or in
conditions.
hermetically sealed enclosures or current-carrying contact surfaces
should not be coated.
b.
Electromagnetic interference suppression (EMI), when required, should
conform to the EMI suppression requirements and test limits for class
C3, group I equipment as specified in MIL-STD-461. The system should
be subjected to tests to determine conformance in accordance with
MIL-STD-462.
Acquisition documents should specify the
6.2 Acquisition requirements.
following:
Title, number, and date of the specification.
Issue of DODISS to be cited in the solicitation, and if required, the
specific issue of individual documents referenced (see 2.1.1 and
2.2).
c.
When either horizontal or vertical splitting of casing is specified
(see 3.1).
d.
When a first article is required (see 3.2 and 6.6).
Size of intake and discharge connection, if different (see 3.6).
e.
If flanged elbows are not required (see 3.6).
f.
When major performance requirements are other than as stated (see
g.
3.7); flow in gpm, total dynamic head in feet, and liquid suction
head in feet.
h.
When battery(s) is not to be maintenance free (see 3.9.2).
When dry-charged type battery(s) is required (see 3.9.2).
i.
When an auxiliary priming system is not required (see 3.10.2).
j.
When an auxiliary lighting system is not required (see 3.10.3).
k.
11
